STUDIO / AUDIO BOOTH
A studio / audio booth is an isolation booth with excellent sound absorption which controls reverberation and modulates the sound. We use dual functional acoustic panels for making the booth totally soundproof. The material used for sound absorption and noise control could vary based on the size of the room and the quality of acoustic desired. We use a selection that comprises of fibreglass, foam and resin based products. We can also vary the shape of the booth if the client prefers like pentagon with five side which helps to minimise the standing waves.
We manufacture high performance audio booths that can be custom engineered to suit the clients’ requirements. Our studio / audio booths are a complete setup with electrical fittings, ventilation vents, doors and windows with the intent to give a traditional interior feel.
We make four performance level soundproof booths with NIC 50, NIC 53, NIC 60 and NIC 70. At Envirotech Systems we are committed to delivering the best quality studio booths.
We manufacture high performance audio booths that can be custom engineered to suit the clients’ requirements. Our studio / audio booths are a complete setup with electrical fittings, ventilation vents, doors and windows with the intent to give a traditional interior feel.
We make four performance level soundproof booths with NIC 50, NIC 53, NIC 60 and NIC 70. At Envirotech Systems we are committed to delivering the best quality studio booths.
AUDIOMETRIC SCREENING BOOTH
The audiometric screening booth provides total sound isolation. It has a standard size door for comfortable entry and exit. The size of the booth varies and has been built to be spacious and comfortable inside. Inside the booth one can experience good sound reduction. The window is sound proof and offers high quality visibility. The magnetic seal of the door ensure that there is no noise leakage and that the door shuts tight.
The sound control level in the audiometric booth is 80. As per standards a speech between 75 and 80 is audible sound but unintelligible, and speech above 80 is inaudible to normal humans.
Noise Reduction performance:
The formal laboratory investigation of “insertion loss” revealed a very high noise reduction of 29 – 49dB(A) overthe hearing test frequencies (pitch), resulting in excellentreduction of unwanted external noises.
We also make customised booths which are available in variable sizes and specifications. All our audiometric booths are tested for highest quality sound isolation.
The sound control level in the audiometric booth is 80. As per standards a speech between 75 and 80 is audible sound but unintelligible, and speech above 80 is inaudible to normal humans.
- A popular, standard double-wall booth with structurally isolated inner room, offering a “high” level of attenuation
- Complete design, and advice service
- Compliance with ISO Standard for Hearing Screening
- Made to order Design Booths and Rooms
- Specialist cabling
- Silent ventilation
- Specialist paint finishes
- To prevent unwanted noise entering the test environment and affecting the integrity of the test procedures to be undertaken.
- To keep patients’ consultations private. A raised voice is often required to communicate with the patients attending an Audiology department, therefore it is as important for these conversations to be kept within the room as it is for the prevention of unwanted noise to enter.
Noise Reduction performance:
| Octave Band Frequency (Hz) | Noise Reduction (dB) |
| 125 | 18 |
| 250 | 32 |
| 500 | 38 |
| 1000 | 44 |
| 2000 | 51 |
| 4000 | 52 |
| 8000 | 50 |
We also make customised booths which are available in variable sizes and specifications. All our audiometric booths are tested for highest quality sound isolation.
